UCC5870QDWJRQ1 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 36-BSSOP (0.295, 7.50mm Width)
- Description: AUTOMOTIVE, FUNCTIONAL SAFETY CO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UCC5870QDWJRQ1 Specifications:
- MfrPart.: UCC5870QDWJRQ1
- Mfr: Texas Instruments
- Description: AUTOMOTIVE, FUNCTIONAL SAFETY CO
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q100, Functional Safety (FuSa)
- PartStatus: Active
- DrivenConfiguration: Full-Bridge
- ChannelType: Single
- NumberofDrivers: 1
- GateType: IGBT, SiC MOSFET
- Voltage-Supply: 3V ~ 5.5V, 15V ~ 30V
- LogicVoltage-VILVIH: 1.5V, 3V
- Current-PeakOutput(SourceSink): 15A, 15A
- InputType: Inverting
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 150ns, 150ns
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 36-BSSOP (0.295, 7.50mm Width)
- UCC5870QDWJRQ1 TI, AUTOMOTIVE, FUNCTIONAL SAFETY CO, Integrated Circuits (ICs)~PMIC - Gate Drivers
UCC5870QDWJRQ1, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
