UCC27282QDQ1 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: 120V LOW COST HS/LS DRIVER- D PK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UCC27282QDQ1 Specifications:
- MfrPart.: UCC27282QDQ1
- Mfr: Texas Instruments
- Description: 120V LOW COST HS/LS DRIVER- D PK
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: Automotive, AEC-Q100
- PartStatus: Active
- DrivenConfiguration: Half-Bridge
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: N-Channel MOSFET
- Voltage-Supply: 5.5V ~ 16V
- LogicVoltage-VILVIH: 0.9V, 2.4V
- Current-PeakOutput(SourceSink): 2.5A, 3.5A
- InputType: Non-Inverting
- HighSideVoltage-Max(Bootstrap): 120 V
- Rise/FallTime(Typ): 12ns, 10ns
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- UCC27282QDQ1 TI, 120V LOW COST HS/LS DRIVER- D PK, Integrated Circuits (ICs)~PMIC - Gate Drivers
UCC27282QDQ1, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
