UCC21530DWK TI IC GATE DRVR ISOLATED
UCC21530DWK Images
UCC21530DWK Images
UCC21530DWK
  • Manufacturer: Texas Instruments (TI)
  • Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 14-SOIC (0.295, 7.50mm Width)
  • Description: IC GATE DRVR ISOLATED
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
UCC21530DWK Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
UCC21530DWK Specifications:
  • MfrPart.: UCC21530DWK
  • Mfr: Texas Instruments
  • Description: IC GATE DRVR ISOLATED
  • Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • DrivenConfiguration: Half-Bridge
  • ChannelType: Independent
  • NumberofDrivers: 2
  • GateType: IGBT, N-Channel, P-Channel MOSFET
  • Voltage-Supply: 3V ~ 18V
  • LogicVoltage-VILVIH: 1.2V, 1.6V
  • Current-PeakOutput(SourceSink): 4A, 6A
  • InputType: CMOS/TTL
  • HighSideVoltage-Max(Bootstrap): -
  • Rise/FallTime(Typ): 6ns, 7ns
  • OperatingTemperature: -40°C ~ 130°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: 14-SOIC (0.295, 7.50mm Width)
  • UCC21530DWK TI, IC GATE DRVR ISOLATED, Integrated Circuits (ICs)~PMIC - Gate Drivers
