UC2950T TI SWITCH 1/2 BRIDGE, BI-POLAR
UC2950T Images
UC2950T Images
  • Manufacturer: Texas Instruments (TI)
  • Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: TO-220-5
  • Description: SWITCH 1/2 BRIDGE, BI-POLAR
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
UC2950T Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
UC2950T Specifications:
  • MfrPart.: UC2950T
  • Mfr: Texas Instruments
  • Description: SWITCH 1/2 BRIDGE, BI-POLAR
  • Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • OutputConfiguration: Half Bridge
  • Applications: General Purpose
  • Interface: On/Off
  • LoadType: Inductive, Capacitive
  • Technology: Bipolar
  • RdsOn(Typ): -
  • Current-Output/Channel: 2A
  • Current-PeakOutput: 4A
  • Voltage-Supply: 8V ~ 35V
  • Voltage-Load: 8V ~ 35V
  • OperatingTemperature: -20°C ~ 100°C (TJ)
  • Features: 5V Regulated Output
  • FaultProtection: Over Temperature
  • MountingType: Through Hole
  • Package/Case: TO-220-5
  • UC2950T TI, SWITCH 1/2 BRIDGE, BI-POLAR, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
UC2950T, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
