TS12A4514P Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 8-DIP (0.300, 7.62mm)
- Description: IC SWITCH SPST 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TS12A4514P Specifications:
- MfrPart.: TS12A4514P
- Mfr: Texas Instruments
- Description: IC SWITCH SPST 8DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 1
- On-StateResistance(Max): 10Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): 2.7V ~ 12V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 75ns, 45ns
- -3dbBandwidth: 520MHz
- ChargeInjection: -11.5pC
- ChannelCapacitance(CS(off)CD(off)): 7.5pF, 7.5pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- TS12A4514P TI, IC SWITCH SPST 8DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
TS12A4514P, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
