TPS7301QD Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: IC REG LIN POS ADJ 500MA 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TPS7301QD Specifications:
- MfrPart.: TPS7301QD
- Mfr: Texas Instruments
- Description: IC REG LIN POS ADJ 500MA 8SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tube
- Series: -
- PartStatus: Active
- OutputConfiguration: Positive
- OutputType: Adjustable
- NumberofRegulators: 1
- Voltage-Input(Max): 10V
- Voltage-Output(Min/Fixed): 1.2V
- Voltage-Output(Max): 9.75V
- VoltageDropout(Max): 0.21V @ 200mA
- Current-Output: 500mA
- Current-Quiescent(Iq): -
- Current-Supply(Max): 550 µA
- PSRR: 68dB (100Hz)
- ControlFeatures: Enable
- ProtectionFeatures: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- TPS7301QD TI, IC REG LIN POS ADJ 500MA 8SOIC, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
TPS7301QD, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
