TPS1120D Images
- Manufacturer: Texas Instruments (TI)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: MOSFET 2P-CH 15V 1.17A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TPS1120D Specifications:
- MfrPart.: TPS1120D
- Mfr: Texas Instruments
- Description: MOSFET 2P-CH 15V 1.17A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: 2 P-Channel (Dual)
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 15V
- Current-ContinuousDrain(Id)@25°C: 1.17A
- RdsOn(Max)@IdVgs: 180mOhm @ 1.5A, 10V
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 5.45nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: -
- Power-Max: 840mW
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- TPS1120D TI, MOSFET 2P-CH 15V 1.17A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
TPS1120D, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
