TPIC1533DW Images
- Manufacturer: Texas Instruments (TI)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 24-SOIC (0.295, 7.50mm Width)
- Description: 1.5A, 20V, N-CHANNEL, MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TPIC1533DW Specifications:
- MfrPart.: TPIC1533DW
- Mfr: Texas Instruments
- Description: 1.5A, 20V, N-CHANNEL, MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: 5 N-Channel, Common Source
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 20V
- Current-ContinuousDrain(Id)@25°C: 1.5A (Tc)
- RdsOn(Max)@IdVgs: 300mOhm @ 2A, 10V
- Vgs(th)(Max)@Id: 2.35V @ 5mA
- GateCharge(Qg)(Max)@Vgs: 3.1nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: 120pF @ 14V
- Power-Max: 2.86W (Tc)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 24-SOIC (0.295, 7.50mm Width)
- TPIC1533DW TI, 1.5A, 20V, N-CHANNEL, MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
TPIC1533DW, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
