TMUX1109PWR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- Description: IC SWITCH DUAL 16TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TMUX1109PWR Specifications:
- MfrPart.: TMUX1109PWR
- Mfr: Texas Instruments
- Description: IC SWITCH DUAL 16TSSOP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: -
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 4Ohm
- Channel-to-ChannelMatching(ΔRon): 180mOhm
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±2.75V
- SwitchTime(TonToff)(Max): 12ns, 6ns (Typ)
- -3dbBandwidth: 135MHz
- ChargeInjection: -1pC
- ChannelCapacitance(CS(off)CD(off)): 7.5pF, 32pF
- Current-Leakage(IS(off))(Max): 80pA
- Crosstalk: -90dB ~ -80dB @ 1MHz ~ 10MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- TMUX1109PWR TI, IC SWITCH DUAL 16TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
TMUX1109PWR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
