TIL117 Images
- Manufacturer: Texas Instruments (TI)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-DIP (0.300, 7.62mm)
- Description: TRANSISTOR OUTPUT OPTOCOUPLER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TIL117 Specifications:
- MfrPart.: TIL117
- Mfr: Texas Instruments
- Description: TRANSISTOR OUTPUT OPTOCOUPLER
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CurrentTransferRatio(Min): 50% @ 10mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 10µs, 9µs
- Rise/FallTime(Typ): 6µs, 8µs
- InputType: DC
- OutputType: Transistor with Base
- Voltage-Output(Max): 80V
- Current-Output/Channel: -
- Voltage-Forward(Vf)(Typ): 1.32V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 400mV
- OperatingTemperature: -55°C ~ 110°C
- MountingType: Through Hole
- Package/Case: 6-DIP (0.300, 7.62mm)
- TIL117 TI, TRANSISTOR OUTPUT OPTOCOUPLER, Isolators~Optoisolators - Transistor, Photovoltaic Output
TIL117, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
