SN74LVC1G3157DCK3 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 6-TSSOP, SC-88, SOT-363
- Description: LOGIC GATE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74LVC1G3157DCK3 Specifications:
- MfrPart.: SN74LVC1G3157DCK3
- Mfr: Texas Instruments
- Description: LOGIC GATE
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Cut Tape (CT),Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 1
- On-StateResistance(Max): 15Ohm
- Channel-to-ChannelMatching(ΔRon): 200mOhm
- Voltage-SupplySingle(V+): 1.65V ~ 5.5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 6ns, 4ns
- -3dbBandwidth: 340MHz
- ChargeInjection: 7pC
- ChannelCapacitance(CS(off)CD(off)): 5.2pF
- Current-Leakage(IS(off))(Max): 1µA
- Crosstalk: -54dB @ 10MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 6-TSSOP, SC-88, SOT-363
- SN74LVC1G3157DCK3 TI, LOGIC GATE, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
SN74LVC1G3157DCK3, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
