SN74LVC1G14DRLR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: SOT-5
- Description: SN74LVC1G14 SINGLE SCHMITT-TRIGG
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74LVC1G14DRLR Specifications:
- MfrPart.: SN74LVC1G14DRLR
- Mfr: Texas Instruments
- Description: SN74LVC1G14 SINGLE SCHMITT-TRIGG
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Bulk
- Series: 74LVC
- PartStatus: Active
- LogicType: Inverter
- NumberofCircuits: 1
- NumberofInputs: 1
- Features: Schmitt Trigger
- Voltage-Supply: 1.65V ~ 5.5V
- Current-Quiescent(Max): 10 µA
- Current-OutputHighLow: 32mA, 32mA
- LogicLevel-Low: 0.39V ~ 1.87V
- LogicLevel-High: 1.16V ~ 3.33V
- MaxPropagationDelay@VMaxCL: 5ns @ 5V, 50pF
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-5
- SN74LVC1G14DRLR TI, SN74LVC1G14 SINGLE SCHMITT-TRIGG, Integrated Circuits (ICs)~Logic - Gates and Inverters
SN74LVC1G14DRLR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
