PT7715C Images
- Manufacturer: Texas Instruments (TI)
- Category: Power Supplies - Board Mount~DC DC Converters Package/Case: 27-SMD Module
- Description: SWITCHING REGULATOR
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PT7715C Specifications:
- MfrPart.: PT7715C
- Mfr: Texas Instruments
- Description: SWITCHING REGULATOR
- Product Category: Power Supplies - Board Mount~DC DC Converters
- Package: Tray
- Series: Excalibur™ PT7715
- PartStatus: Obsolete
- Type: Non-Isolated PoL Module
- NumberofOutputs: 1
- Voltage-Input(Min): 4.5V
- Voltage-Input(Max): 5.5V
- Voltage-Output1: 1.075 ~ 1.85V
- Voltage-Output2: -
- Voltage-Output3: -
- Voltage-Output4: -
- Current-Output(Max): 20A
- Power(Watts): -
- Voltage-Isolation: -
- Applications: ITE (Commercial)
- Features: Remote On/Off, OCP
- OperatingTemperature: -40°C ~ 85°C
- Efficiency: 82%
- MountingType: Surface Mount
- Package/Case: 27-SMD Module
- Size/Dimension: 3.00 L x 1.19 W x 0.50 H (76.2mm x 30.2mm x 12.7mm)
- SupplierDevicePackage: -
- ControlFeatures: Enable, Active High
- ApprovalAgency: -
- PT7715C TI, SWITCHING REGULATOR, Power Supplies - Board Mount~DC DC Converters
PT7715C, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
