PT4314C Images
- Manufacturer: Texas Instruments (TI)
- Category: Power Supplies - Board Mount~DC DC Converters Package/Case: 18-SMD Module, 9 Leads
- Description: DC DC CONVERTER +/-24V 6W
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PT4314C Specifications:
- MfrPart.: PT4314C
- Mfr: Texas Instruments
- Description: DC DC CONVERTER +/-24V 6W
- Product Category: Power Supplies - Board Mount~DC DC Converters
- Package: Tray
- Series: PT4310 (6W)
- PartStatus: Obsolete
- Type: Isolated Module
- NumberofOutputs: 2
- Voltage-Input(Min): 38V
- Voltage-Input(Max): 75V
- Voltage-Output1: 24V
- Voltage-Output2: -24V
- Voltage-Output3: -
- Voltage-Output4: -
- Current-Output(Max): 250mA, 250mA
- Power(Watts): 6 W
- Voltage-Isolation: 1.5 kV
- Applications: ITE (Commercial)
- Features: Remote On/Off, UVLO
- OperatingTemperature: -40°C ~ 85°C
- Efficiency: 82%
- MountingType: Surface Mount
- Package/Case: 18-SMD Module, 9 Leads
- Size/Dimension: 1.90 L x 1.21 W x 0.32 H (48.3mm x 30.7mm x 8.0mm)
- SupplierDevicePackage: -
- ControlFeatures: -
- ApprovalAgency: -
- PT4314C TI, DC DC CONVERTER +/-24V 6W, Power Supplies - Board Mount~DC DC Converters
PT4314C, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
