LM3302N Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Linear - Comparators Package/Case: 14-DIP (0.300, 7.62mm)
- Description: IC COMPARATOR QUAD 14-DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LM3302N Specifications:
- MfrPart.: LM3302N/NOPB
- Mfr: Texas Instruments
- Description: IC COMPARATOR QUAD 14-DIP
- Product Category: Integrated Circuits (ICs)~Linear - Comparators
- Package: Tube
- Series: -
- PartStatus: Obsolete
- Type: General Purpose
- NumberofElements: 4
- OutputType: CMOS, DTL, ECL, MOS, Open-Collector, TTL
- Voltage-SupplySingle/Dual(±): 2V ~ 28V, ±1V ~ 14V
- Voltage-InputOffset(Max): 20mV @ 28V
- Current-InputBias(Max): 0.5µA @ 5V
- Current-Output(Typ): 16mA @ 5V
- Current-Quiescent(Max): 2.5mA
- CMRRPSRR(Typ): -
- PropagationDelay(Max): -
- Hysteresis: -
- OperatingTemperature: -40°C ~ 85°C
- Package/Case: 14-DIP (0.300, 7.62mm)
- MountingType: Through Hole
- LM3302N TI, IC COMPARATOR QUAD 14-DIP, Integrated Circuits (ICs)~Linear - Comparators
LM3302N, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
