ISO5500DWR Images
- Manufacturer: Texas Instruments (TI)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 16-SOIC (0.295, 7.50mm Width)
- Description: DGTL ISO 4.243KV GATE DVR 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ISO5500DWR Specifications:
- MfrPart.: ISO5500DWR
- Mfr: Texas Instruments
- Description: DGTL ISO 4.243KV GATE DVR 16SOIC
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- Technology: Capacitive Coupling
- NumberofChannels: 1
- Voltage-Isolation: 4243Vrms
- CommonModeTransientImmunity(Min): 25kV/µs
- PropagationDelaytpLH/tpHL(Max): 300ns, 300ns
- PulseWidthDistortion(Max): -
- Rise/FallTime(Typ): 55ns, 10ns
- Current-OutputHighLow: 2.5A, 2.5A
- Current-PeakOutput: 2.5A
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- Voltage-OutputSupply: 15V ~ 30V
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.295, 7.50mm Width)
- ISO5500DWR TI, DGTL ISO 4.243KV GATE DVR 16SOIC, Isolators~Isolators - Gate Drivers
ISO5500DWR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
