CSD86350Q5DT TI 25V POWERBLOCK N CH MOSFET
CSD86350Q5DT Images
CSD86350Q5DT Images
  • Manufacturer: Texas Instruments (TI)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-PowerLDFN
  • Description: 25V POWERBLOCK N CH MOSFET
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
CSD86350Q5DT Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
CSD86350Q5DT Specifications:
  • MfrPart.: CSD86350Q5DT
  • Mfr: Texas Instruments
  • Description: 25V POWERBLOCK N CH MOSFET
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • FETType: 2 N-Channel (Half Bridge)
  • FETFeature: Standard
  • DraintoSourceVoltage(Vdss): 25V
  • Current-ContinuousDrain(Id)@25°C: 40A (Ta)
  • RdsOn(Max)@IdVgs: 5mOhm @ 25A, 5V, 1.1mOhm @ 25A, 5V
  • Vgs(th)(Max)@Id: 2.1V @ 250µA, 1.6V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 10.7nC, 25nC @ 4.5V
  • InputCapacitance(Ciss)(Max)@Vds: 1870pF, 4000pF @ 12.5V
  • Power-Max: 13W (Ta)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: 8-PowerLDFN
  • CSD86350Q5DT TI, 25V POWERBLOCK N CH MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
CSD86350Q5DT, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
