CSD86311W1723 Images
- Manufacturer: Texas Instruments (TI)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 12-UFBGA, DSBGA
- Description: MOSFET 2N-CH 25V 4.5A 12DSBGA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CSD86311W1723 Specifications:
- MfrPart.: CSD86311W1723
- Mfr: Texas Instruments
- Description: MOSFET 2N-CH 25V 4.5A 12DSBGA
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: NexFET™
- PartStatus: Active
- FETType: 2 N-Channel (Dual)
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 25V
- Current-ContinuousDrain(Id)@25°C: 4.5A
- RdsOn(Max)@IdVgs: 39mOhm @ 2A, 8V
- Vgs(th)(Max)@Id: 1.4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 4nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 585pF @ 12.5V
- Power-Max: 1.5W
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 12-UFBGA, DSBGA
- CSD86311W1723 TI, MOSFET 2N-CH 25V 4.5A 12DSBGA, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
