CSD75207W15 Images
- Manufacturer: Texas Instruments (TI)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 9-UFBGA, DSBGA
- Description: MOSFET 2P-CH 3.9A 9DSBGA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CSD75207W15 Specifications:
- MfrPart.: CSD75207W15
- Mfr: Texas Instruments
- Description: MOSFET 2P-CH 3.9A 9DSBGA
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: NexFET™
- PartStatus: Active
- FETType: 2 P-Channel (Dual) Common Source
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): -
- Current-ContinuousDrain(Id)@25°C: 3.9A
- RdsOn(Max)@IdVgs: 162mOhm @ 1A, 1.8V
- Vgs(th)(Max)@Id: 1.1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 3.7nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 595pF @ 10V
- Power-Max: 700mW
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 9-UFBGA, DSBGA
- CSD75207W15 TI, MOSFET 2P-CH 3.9A 9DSBGA, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
CSD75207W15, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
