74LVC1G3157DCKRG4 TI IC SWITCH SPDT SC70-6
74LVC1G3157DCKRG4 Images
74LVC1G3157DCKRG4 Images
  • Manufacturer: Texas Instruments (TI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 6-TSSOP, SC-88, SOT-363
  • Description: IC SWITCH SPDT SC70-6
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
74LVC1G3157DCKRG4 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
74LVC1G3157DCKRG4 Specifications:
  • MfrPart.: 74LVC1G3157DCKRG4
  • Mfr: Texas Instruments
  • Description: IC SWITCH SPDT SC70-6
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SPDT
  • Multiplexer/DemultiplexerCircuit: 2:1
  • NumberofCircuits: 1
  • On-StateResistance(Max): 15Ohm
  • Channel-to-ChannelMatching(ΔRon): 100mOhm
  • Voltage-SupplySingle(V+): 1.65V ~ 5.5V
  • Voltage-SupplyDual(V±): -
  • SwitchTime(TonToff)(Max): 5.7ns, 3.8ns
  • -3dbBandwidth: 300MHz
  • ChargeInjection: 7pC
  • ChannelCapacitance(CS(off)CD(off)): 5.2pF
  • Current-Leakage(IS(off))(Max): 1µA
  • Crosstalk: -54dB @ 10MHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 6-TSSOP, SC-88, SOT-363
  • 74LVC1G3157DCKRG4 TI, IC SWITCH SPDT SC70-6, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
74LVC1G3157DCKRG4, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
